| Design | |
| LED indicators | PLC |
| Product colour | White |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x |
| Wi-Fi | N |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Software | |
| Mac compatibility | Y |
| Mac operating systems supported | Mac OS X 10.9 Mavericks |
| Windows operating systems supported | Windows 7 x64 |
| Power | |
| AC input frequency | 50 Hz |
| AC input voltage | 196 - 250 V |
| Current | 16 A |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 2.8 W |
| Weight & dimensions | |
| Depth | 42 mm |
| Height | 130 mm |
| Width | 66 mm |
| Packaging data | |
| Package height | 231 mm |
| Package width | 188 mm |
| Package depth | 92 mm |
| Package weight | 790 g |
| Certificates | |
| Certification | CE |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Performance | |
| Built-in power socket | Y |
| Damping filter | 2 - 80 MHz |
| Filter characteristics | -22 - -45 dB |
| Maximum data transfer rate | 330 Mbit/s |
| Maximum operating distance | 400 m |
| Power plug | Type F |
| Security | |
| Security algorithms | 128-bit AES |
| System requirements | |
| Linux operating systems supported | Ubuntu 16.04 |
| Mobile operating systems supported | Android 5.1 |
| Wireless LAN features | |
| Modulation | 64-QAM,256-QAM,1024-QAM,4096-QAM,BPSK,QPSK |
