INTEL CORE PROCESSOR I9-11900 2.50/5.20GHZ BX8070811900
- Model: 5032037214988
- Weight: 0.50kg
- Dimensions: 12.20cm x 8.10cm x 7.90cm
- MPN: BX8070811900
INTEL CORE PROCESSOR I9-11900 2.50/5.20GHZ BX8070811900
| Features | |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 20 |
| PCI Express configurations | 1x16+1x4,2x8+1x4,1x8+3x4 |
| PCI Express slots version | 4.0 |
| Scalability | 1S |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0,AVX-512 |
| Thermal Monitoring Technologies | Y |
| Use conditions | PC/Client/Tablet |
| Weight & dimensions | |
| Processor package size | 37.5 x 37.5 mm |
| Packaging data | |
| Package type | Retail box |
| Graphics | |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| Number of execution units | 32 |
| On-board graphics card | Y |
| On-board graphics card 4K support | Y |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1300 MHz |
| On-board graphics card ID | 0x4C8A |
| On-board graphics card maximum resolution (DisplayPort) | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card model | Intel UHD Graphics 750 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| Logistics data | |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Harmonized System (HS) code | 8542310001 |
| Memory | |
| ECC | N |
| Maximum internal memory | 128 GB |
| Maximum internal memory supported by processor | 128 GB |
| Memory bandwidth (max) | 50 GB/s |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 3200 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Operational conditions | |
| Tjunction | 100 °C |
| Processor | |
| Box | Y |
| Component for | PC |
| Memory bandwidth supported by processor (max) | 50 GB/s |
| Processor ARK ID | 212252 |
| Processor base frequency | 2.5 GHz |
| Processor boost frequency | 5.2 GHz |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| Processor cores | 8 |
| Processor family | Intel® Core™ i9 |
| Processor generation | 11th gen Intel® Core™ i9 |
| Processor lithography | 14 nm |
| Processor manufacturer | Intel |
| Processor model | i9-11900 |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1200 (Socket H5) |
| Processor threads | 16 |
| System bus rate | 8 GT/s |
| Thermal Design Power (TDP) | 65 W |
| Processor special features | |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Clear Video Technology | Y |
| Intel Software Guard Extensions (Intel SGX) | N |
| Intel Stable Image Platform Program (SIPP) | Y |
| Intel Trusted Execution Technology | Y |
| Intel Turbo Boost Max Technology 3.0 | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Boot Guard | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Deep Learning Boost (Intel® DL Boost) | Y |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0 | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® InTru™ 3D Technology | Y |
| Intel® Optane™ Memory Ready | Y |
| Intel® OS Guard | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel® Secure Key | Y |
| Intel® Thermal Velocity Boost | Y |
| Intel® Thermal Velocity Boost Frequency | 5.2 GHz |
| Intel® Thermal Velocity Boost Temperature | 70 °C |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.1 GHz |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 5 GHz |
| Intel® vPro™ Platform Eligibility | Y |
| Technical details | |
| Launch date | Q1'21 |
| Status | Launched |
| Supported memory types | DDR4-SDRAM |
| Target market | Gaming, Content Creation |
