INTEL CORE I7-12700F PROCESSOR 2,10/4,90 GHZ BX8071512700F
- Model: 5032037237826
- Weight: 0.44kg
- Dimensions: 12.30cm x 10.70cm x 8.00cm
- MPN: BX8071512700F
INTEL CORE I7-12700F PROCESSOR 2,10/4,90 GHZ BX8071512700F
| Features | |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 20 |
| PCI Express configurations | 1x16+1x4,2x8+1x4 |
| PCI Express slots version | 5.0,4.0 |
| Scalability | 1S |
| Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
| Thermal Monitoring Technologies | Y |
| Use conditions | PC/Client/Tablet |
| Weight & dimensions | |
| Processor package size | 45 x 37.5 mm |
| Packaging data | |
| Package type | Retail box |
| Graphics | |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card | N |
| On-board graphics card model | Not available |
| Logistics data | |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Harmonized System (HS) code | 8542310001 |
| Memory | |
| Maximum internal memory | 128 GB |
| Maximum internal memory supported by processor | 128 GB |
| Memory bandwidth (max) | 76.8 GB/s |
| Memory channels | Dual-channel |
| Memory types supported by processor | DDR4-SDRAM,DDR5-SDRAM |
| Operational conditions | |
| Tjunction | 100 °C |
| Processor | |
| Box | Y |
| Bus type | DMI4 |
| Efficient cores | 4 |
| Efficient-core base frequency | 1.6 GHz |
| Efficient-core boost frequency | 3.6 GHz |
| Maximum number of DMI lanes | 8 |
| Maximum turbo power | 180 W |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Performance cores | 8 |
| Performance-core base frequency | 2.1 GHz |
| Performance-core boost frequency | 4.8 GHz |
| Processor base power | 65 W |
| Processor boost frequency | 4.9 GHz |
| Processor cache | 25 MB |
| Processor cache type | Smart Cache |
| Processor codename | Alder Lake |
| Processor cores | 12 |
| Processor family | Intel® Core™ i7 |
| Processor generation | 12th gen Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor model | i7-12700F |
| Processor operating modes | 64-bit |
| Processor socket | LGA 1700 |
| Processor threads | 20 |
| Processor special features | |
| CPU configuration (max) | 1 |
| Embedded options available | N |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Turbo Boost Max Technology 3.0 | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Boot Guard | Y |
| Intel® Control-flow Enforcement Technology (CET) | Y |
| Intel® Deep Learning Boost (Intel® DL Boost) | Y |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Optane™ Memory Ready | Y |
| Intel® OS Guard | Y |
| Intel® Secure Key | Y |
| Intel® Speed Shift Technology | Y |
| Intel® Thread Director | Y |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.9 GHz |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Volume Management Device (VMD) | Y |
| Mode-based Execute Control (MBE) | Y |
| Technical details | |
| Launch date | Q1'22 |
| Status | Launched |
| Target market | Gaming, Content Creation |
