INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF

INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
INTEL CORE I7 14700KF PROCESSOR 33 MB SMART CACHE BOX BX8071514700KF
  • Model: 5032037278508
  • Weight: 0.08kg
  • Dimensions: 11.60cm x 10.20cm x 4.50cm
  • MPN: BX8071514700KF

Specifications

Features
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Direct Media Interface (DMI) Revision 4.0
Market segment Desktop
Maximum number of PCI Express lanes 20
PCI Express configurations 1x16+1x4, 2x8+1x4
PCI Express slots version 4.0, 5.0
Scalability 1S
Supported instruction sets AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies Yes
Thermal solution specification PCG 2020A
Use conditions PC/Client/Tablet
Weight & dimensions
Processor package size 45 x 37.5 mm
Graphics
Discrete graphics card No
Discrete graphics card model Not available
On-board graphics card No
On-board graphics card model Not available
Logistics data
Export Control Classification Number (ECCN) 5A992C
Harmonized System (HS) code 8542310001
Memory
Maximum internal memory 192 GB
Maximum internal memory supported by processor 192 GB
Memory bandwidth (max) 89.6 GB/s
Memory channels Dual-channel
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Non-ECC Yes
Operational conditions
Tjunction 100 °C
Other features
L2 cache 28672 KB
Processor
Box Yes
Cooler included No
Efficient cores 12
Efficient-core base frequency 2.5 GHz
Efficient-core boost frequency 4.3 GHz
Maximum number of DMI lanes 8
Maximum turbo power 253 W
Memory bandwidth supported by processor (max) 89.6 GB/s
Performance cores 8
Performance-core base frequency 3.4 GHz
Performance-core boost frequency 5.5 GHz
Processor ARK ID 236789
Processor base power 125 W
Processor boost frequency 5.6 GHz
Processor cache 33 MB
Processor cache type Smart Cache
Processor codename Raptor Lake
Processor cores 20
Processor family Intel® Core™ i7
Processor generation Intel® Core™ i7 (14th gen)
Processor manufacturer Intel
Processor model i7-14700KF
Processor operating modes 64-bit
Processor socket LGA 1700
Processor threads 28
Stepping B0
Processor special features
CPU configuration (max) 1
Embedded options available No
Enhanced Intel SpeedStep Technology Yes
Execute Disable Bit Yes
Idle States Yes
Intel 64 Yes
Intel Turbo Boost Max Technology 3.0 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Intel® Boot Guard Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® OS Guard Yes
Intel® Secure Key Yes
Intel® Speed Shift Technology Yes
Intel® Standard Manageability (ISM) Yes
Intel® Thread Director Yes
Intel® Turbo Boost Max Technology 3.0 frequency 5.6 GHz
Intel® Turbo Boost Technology 2.0
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Technical details
Launch date Q4'23
Status Launched
