MSI PRO Z790-P MOTHERBOARD 911-7E06-062
- Model: 4711377015738
- Weight: 1.56kg
- Dimensions: 34.80cm x 27.00cm x 6.70cm
- MPN: PRO Z790-P WIFI
MSI PRO Z790-P MOTHERBOARD 911-7E06-062
| Design | |
| Product colour | Black |
| Features | |
| Motherboard chipset family | Intel |
| Motherboard form factor | ATX |
| Loudspeakers | |
| Audio output channels | 7.1 channels |
| Network | |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Ethernet LAN | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Ports & interfaces | |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| S/PDIF out port | Yes |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| VGA (D-Sub) ports quantity | 0 |
| Ports & interfaces | |
| DVI-D ports quantity | 0 |
| Software | |
| Bundled software | Drivers MSI Center Intel Extreme Tuning Utility CPU-Z MSI GAMING Norton 360 Deluxe AIDA64 Extreme - MSI Edition |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Weight & dimensions | |
| Depth | 243.8 mm |
| Width | 304.8 mm |
| BIOS | |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| System Management BIOS (SMBIOS) version | 3.5 |
| Expansion slots | |
| Number of M.2 (M) slots | 4 |
| PCI slots | 0 |
| Graphics | |
| On-board graphics card | No |
| Internal I/O | |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| Number of SATA connectors | 0 |
| Number of SATA II connectors | 0 |
| Number of SATA III connectors | 6 |
| RGB LED pin header | Yes |
| TPM connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Memory | |
| ECC сompatibility | Non-ECC |
| Maximum internal memory | 128 GB |
| Number of memory slots | 4 |
| Supported memory clock speed (max) | 7000 MHz |
| Supported memory clock speeds | 4800,5000,5200,5400,5800,6000,6400,6600,6800,7000 MHz |
| Other features | |
| mSATA ports quantity | 0 |
| USB 2.0 connectors | 4 |
| Packaging content | |
| Cables included | SATA |
| Performance | |
| Audio chip | Realtek ALC897 |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® Gold |
| Motherboard chipset | Intel Z790 |
| Supported processor sockets | LGA 1700 |
| Processor | |
| Component for | PC |
| Parallel processing technology support | Not supported |
| Processor manufacturer | Intel |
| Processor socket | LGA 1700 |
| Rear panel I/O ports | |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Storage | |
| Internal storage capacity | 10 GB |
| RAID levels | 0, 1, 5, 10 |
| RAID support | Yes |
| Supported storage drive interfaces | M.2, PCI Express |
| Supported storage drive types | HDD & SSD |
| Technical details | |
| Supported memory types | DDR5-SDRAM |
