TP-LINK SWITCH 8 PORT GIGA TL-SG108 V3

TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA  TL-SG108 V3
TP-LINK SWITCH 8 PORT GIGA TL-SG108 V3
What This Product Does
The TP-LINK 8 10/100/1000Mbps Desktop Switch TL-SG108 provides you an easy way to make the transition to gigabit Ethernet. Increase the speed of your network server and backbone connections, or make gigabit to the desktop a reality. Moreover, TL-SG108 adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG108 can save up to 72% of the power consumption, making it an eco-friendly solution for your home or office network.

Gigabit Switch
Featured with 8 10/100/1000Mbps ports, TL-SG108 greatly expands your network capacity, enabling instant large files transferring. So,power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.

Go Green With Your Ethernet
You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG108 features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

- Power down Idle Ports
When a computer or network equipment is off, the corresponding port of a traditional switch will continue to consume considerable amounts of power. The TL-SG108 can automatically detect the link status of each port and reduce the power consumption of ports that are idle, resulting in up to an 72% reduction in power use.
- Power Budget According to Cable Length
Ideally, shorter cable would use less power because of less power degradation over their length; this is not the case with most devices as they will use the same amount of power across the cable regardless of the length.

Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.
  • Model: 6935364098117
  • Weight: 1.00kg
  • Dimensions: 16.00cm x 10.00cm x 3.00cm
  • MPN: TL-SG108 V4

Specifications

Design
LED indicators Y
Product colour Black
Other features
Switch type Unmanaged
Network
10G support N
Auto MDI/MDI-X Y
Bandwidth 16 Gbit/s
Ethernet interface type Gigabit Ethernet
Ethernet LAN Y
Ethernet LAN data rates 10,100,1000 Mbit/s
Flow control support Y
Full duplex Y
Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3x
Wi-Fi N
Ports & interfaces
Connectivity technology Wired
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Power connector DC-in jack
Power
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
DC input voltage 9 V
Input current 0.6 A
Power consumption (max) 3.31 W
Power over Ethernet (PoE) N
Weight & dimensions
Depth 100.7 mm
Height 25.4 mm
Width 158 mm
Packaging data
Package height 92 mm
Package width 191 mm
Package depth 130 mm
Certificates
Certification CE, FCC, RoHS
Data transmission
Forwarding rate 11.9 Mpps
Jumbo frames 16000
Jumbo frames support Y
MAC address table 4000 entries
Packet buffer memory 1.5 MB
Store-and-forward Y
Supported data transfer rates 10/100/1000Mbps
Multicast features
Multicast Listener Discovery (MLD) snooping Y
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Storage relative humidity (H-H) 5 - 90%
Storage temperature (T-T) -40 - 70 °C
Other features
Packet transfer speed 14880pps/148800pps/1488000pps
Power LED Y
Packaging content
User guide Y
Performance
Maximum data transfer rate 2 Gbit/s
Quality of Service (QoS) support Y
Power supply
Power supply included Y
Protocols
Switching protocols CSMA/CD
Security
IGMP snooping Y
